65-9007-25 ［Discontinued］SP-A Coupler R1 1/4 Brass 1520 g 10S-ABRASSFKM
Product Description
Product Model: 65-9007-25Product Brand: NITTO KOHKI CO. […]
Contact Us
Product Details
Product Model: 65-9007-25
Product Brand: NITTO KOHKI CO., LTD.
Features
- For medium pressure.
- Both the socket and plug are equipped with automatic opening and closing valves to prevent fluid outflow during separation.
- Various body materials, sizes and mounting shapes have been standardized to meet a wide range of applications and conditions.
- Compatibility: Cannot connect if the size is different. Can be connected to traditional SP Couplers (same size).
Spec
- Counterpart Mounting Screw Size: R1 1/4
- Body Material: Brass
- Mass (g): 1520
- L(mm):115
- ΦD(mm):77
- H (mm): two sides 54
- T:Rc1 1/4
- Valve Structure: Double Road Opening/Closing Type
- Maximum Working Pressure (MPa{kgf/cm2}): 2.0{20}
- Pressure Capacity (MPa{kgf/cm2}): 3.0{31}
- Seal Material: Fluororubber
- display symbols: FKM
- Operating Temperature Range (°C): -20 to +180
- Remarks: Standard Material
- Recomm***ed maximum tightening torque (N · m{kgf · cm}): 150{1530}
- Type: Socket
