4-3493-01 Barcoater approx. φ76.2μm No.3
model:
4-3493-01
category:
toner
Product Description
Product Model: 4-3493-01 Features Stainless steel wire […]
Contact Us
Product Details
Product Model: 4-3493-01
Features
- Stainless steel wire is wrapped around the stainless steel rod without gaps, and this spacing provides uniform film thickness.
- It ***s a 9.5 mm(3/8 inch) core with less deflection and stability when applied.
- The thickness of the film dep***s on the wire count (wire diameter).
- It is handheld and easy to apply.
- Several types of paint can be applied at the same time for comparison.
Spec
- Wire diameter (micrometer): about phi 76.2
- Reference: Wet film thickness (micrometers): 7.6
- Number of entries: 1
- Material: Core/SUS 303, Wire (strand)/SUS 302
- Core diameter: phi 9.5 mm (3/8 inch)
- Total length: 406 mm (16 inches)
- Application width guideline: 304 mm (12 inches)
- *Reference Wet film thickness (micrometers) is a reference value. It dep***s on the application material such as paint ***d and the speed at which the barcoater is pulled.
