Spec

• Power supply: Single phase 200V ±10% 50/60Hz, Approximately 640VA
• Outline dimensions (mm): Width 303 x Depth 365 x Height 168
• Mass: Approx 9kg
• High-frequency output: Maximum 300W
• Circuit configuration: Main oscillator power increasing method
• Oscillation mode: AM/FM modulation method
• Oscillation frequency: 24 - 28kHz (modulation frequency range ±0.5kHz)
• Display: Power ON, Ultrasonic ON, Bar LED for output
• External input: External drive signal
• Cooling method: Forced air cooling method
• Ambient temperature, humidity range: 5 - 40℃, Relative humidity/35 - 80%RH (no condensation)
• Contact rating for external drive: Use available contact (contact capacity DC15 - 20mA or more). (Non-contact method such as transistor and TRIAC is unavailable)
• Accessories: Grounded wire 5m, 1 piece
