63-8446-32 IXYS, MMO90-12io6, Dual Thyristor Module, SCR, 50A 1200V, 4-Pin SOT-227B MMO90-12io6
Product Description
Product Model: 63-8446-32Product Brand: IXYS Features M […]
Contact Us
Product Details
Product Model: 63-8446-32
Product Brand: IXYS
Features
- MMO series AC Thyristor Modules. A range of AC power control thyristor modules from IXYS. The modules contain two back-to-back thyristors allowing full-wave AC power control. The devices ho***d in isolated base SOT227B packages and are available with average current ratings of up to 50A, with reverse voltage ratings of 1200V and 1600V. Industry standard outline Isolated copper baseplate for good heat transfer Two-hole screw fixing M4 screw terminal connections 3000Vac isolation rating
Spec
- Quantity:1piece
- Thyristor Type:SCR
- Maximum Gate Trigger Voltage:1.6V
- Maximum Gate Trigger Current:200mA
- Maximum Holding Current:100mA
- Rated Average On-State Current:50A
- Repetitive Peak Reverse Voltage:1200V
- Surge Current Rating:865A
- Mounting Type:Surface Mount
- Package Type:SOT-227B
- Pin Count:4
- Repetitive Peak Forward Blocking Voltage:1200V
- Dimensions:38.23 x 25.25 x 12.22mm
- Minimum Operating Temperature:-40 °C
- CODE No.:135-8267
