63-8422-82 XP Power JWE06 6W Isolated DC-DC Converter PCB Mount, Voltage in 9 → 36 V dc, Voltage out ±15V dc JWE0624D15
Product Description
Product Model: 63-8422-82Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-8422-82
Product Brand: XP Power
Features
- XP Power - JWE Series of 6 W DC-DC Isolated Converters. The JWE06 Series of DC-DC Converters from XP Power are available in single or dual outputs with an ultra wide 4:1 input range. Available in DIP 6 Package, ITE Safety Approved and high-power density. Features and Benefits. Regulated Single and Dual Output ITE Safety Approvals Ultra wide 4:1 Input Range DIP 16 Package Operating Temperature -40 °C to +105 °C 1500 VDC Isolation Full Power to +75 °C High-power density Metal case 3-Year Warranty
Spec
- Quantity:1piece
- Output Voltage:±15V dc
- Input Voltage Range:9 → 36 V dc
- Input Voltage Nominal:24 V dc
- Isolation Voltage:1.5kV dc
- Power Rating:6W
- Output Current:±200mA
- Mounting Type:PCB Mount
- Number of Outputs:2
- Package:DIP 16
- Load Regulation:±1%
- Maximum Temperature:+105°C
- Series:JWE06
- CODE No.:135-1363
