Electronic/Electrical Parts and Controll Equipments
63-8410-93 ifm electronic RTD Sensor, -20°C min +115°C max, 42mm Probe Length x M6 Probe Diameter ATEX TS522A
model:
63-8410-93
brand:
ifm electronic
Product Description
Product Model: 63-8410-93Product Brand: ifm electronic […]
Contact Us
Product Details
Product Model: 63-8410-93
Product Brand: ifm electronic
Features
- ifm Electronic TR Series Temperature Transmitter. Ifm Electronic TR series temperature sensors evaluation unit is a universal control and display unit for connection of Pt100 / Pt1000 sensors. TR series sensors automatically detects whether two, three or four wire sensors are connected. The measuring range has freely scalable parameters that can bet set via an integrated IO-Link interface. A simple three push button operation with integrated display allows switching states to be highlighted. The sensor head can be rotated and offers optimum readability from any position. Features and Benefits. IO-Link interface 4-digit alphanumeric display LED status indicators IP67 Rated Flexible installation
Spec
- Quantity:1piece
- Sensor Type:PT100
- Probe Length:42mm
- Probe Diameter:M6
- Minimum Temperature Sensed:-20°C
- Maximum Temperature Sensed:+115°C
- Termination Type:Cable
- Cable Length:5m
- Response Time:13 (T05) s, 39 (T09) s
- Hazardous Area Certification:ATEX
- CODE No.:134-8540
Related product recommendations
You may also be interested in the following products
Electronic/Electrical Parts and Controll Equipments
63-8303-45 TRACOPOWER TSH 2W Isolated DC-DC Converter Surface Mount, Voltage in 4.5 → 5.5 V dc, Voltage out ±12V dc TSH 0512D
