63-8345-82 Murata LQM18PN_FR Series 2.2 μH ±20% Ferrite Multilayer SMD Inductor, 0603 (1608M) Case, 750mA dc 300mΩ Rdc LQM18PN2R2MFRL
Product Description
Product Model: 63-8345-82Product Brand: Murata Features […]
Contact Us
Product Details
Product Model: 63-8345-82
Product Brand: Murata
Features
- LQM18PN Series SMD Chip Inductors. Murata LQM Series Surface mount film chip inductors feature a multilayer type ferrite core which enables a current rating of up to 1800 mA. These multilayer inductors offer a wide range of current ratings, inductance values and sizes. The LQM inductors feature a magnetically shielded structure and has a low DC resistance. LQM Inductors are ideal for *** in voltage conversion, resonance circuit and low frequency applications. Applications. Digital Cameras TV Mobile phones Game machines HDD
Spec
- Quantity:1set(4000pieces)
- Series:LQM18PN_FR
- Inductance:2.2 μH
- Tolerance:±20%
- Maximum DC Current:750mA
- Package/Case:0603 (1608M)
- Maximum DC Resistance:300mΩ
- Core Material:Ferrite
- Dimensions:1.6 x 0.8 x 0.8mm
- Depth:0.8mm
- Height:0.8mm
- Length:1.6mm
- Maximum Operating Temperature:+85°C
- Minimum Operating Temperature:-40°C
- CODE No.:166-9882
