63-8184-67 HY Electronic Corp W06G, Bridge Rectifier, 1.5A 600V, 4-Pin WOG W06G
model:
63-8184-67
brand:
HY Electronic Corp
Product Description
Product Model: 63-8184-67Product Brand: HY Electronic C […]
Contact Us
Product Details
Product Model: 63-8184-67
Product Brand: HY Electronic Corp
Features
- Bridge Rectifier - WO Series. The HY Electronic (Cayman) Limited WO Series glass passivated bridge rectifiers have s 1.5 Amp forward current. They have reverse voltages that range from 400 V up to 1000 V. The bridge rectifier converts AC to DC and you find them on many Printed Circuit Boards (PCB) applications.. WO/WOM Series: Silicon Passivated Bridge Rectifiers WOxG/WOxMG Series: Glass passivated Bridge Rectifiers Surge overload rating: -40 A peak
Spec
- Quantity:1box(1000pieces)
- Bridge Type:Single Phase
- Peak Average Forward Current:1.5A
- Peak Reverse Repetitive Voltage:600V
- Mounting Type:Through Hole
- Package Type:WOG
- Pin Count:4
- Diode Technology:Silicon Junction
- Configuration:Single
- Peak Non-Repetitive Forward Surge Current:50A
- Maximum Operating Temperature:+150 °C
- Minimum Operating Temperature:-55 °C
- Peak Forward Voltage:1V
- Peak Reverse Current:5µA
- Length:9.86mm
- Dimensions:9.86 x 8.84 x 5.6mm
- CODE No.:171-1436
Related product recommendations
You may also be interested in the following products
Electronic/Electrical Parts and Controll Equipments
63-7377-54 Spherical Metric Roller Bearing 20mm I.D, 42mm O.D 146-9306
