Features

• Vertical Light Guides, 1 Row - Rectangular (Bargraph). This family of vertical light guides, from MENTOR, consist of one row of light pipes. These light guides are ideal for *** in bargraph displays with a minimum of 4 displays. The rectangular heads are parallel to the printed board on the front panel. This range of single level light guides is available in single or multiple column arrays with up to 10 sections. Some of the light guides *** a light diffusing cover to prevent radiation when using a combination of different colours. Vertical light pipes are designed for *** with surface mount (SMD) LEDs and are fitted to the circuit board using push-fit lugs. The light pipe inject face sits in close proximity to the LED on the board.. Features of the vertical light guides: Designed for bargraph displays Rectangular heads 1 to 10 columns PC clear UL94 light pipe PC black UL94 screen Ambient temperature: -40°C to +85°C
