63-8048-68 EPCOS 1.6 mH -30 → +50% Ferrite Toroidal Inductor, Max SRF:10kHz, 20A Idc, 4.5mΩ Rdc B82726S B82726S2203A020
Product Description
Product Model: 63-8048-68Product Brand: EPCOS Features […]
Contact Us
Product Details
Product Model: 63-8048-68
Product Brand: EPCOS
Features
- Epcos B82726S Series Toroidal Inductors. B82726S3543N040 Series are Current-Compensated Ring Core double choke with a Ferrite Core Polycarbonate base plate and spacer (UL 94 V-0) Sector winding. Suitable for wave soldering Approx. 1% stray inductance for symmetrical interference suppression thus ideal for Suppression of common-mode interferences and in Switch-mode applications
Spec
- Quantity:1piece
- Inductance:1.6 mH
- Maximum DC Current:20A
- Mounting Type:Radial
- Maximum DC Resistance:4.5mΩ
- Tolerance:-30 → +50%
- Length:45mm
- Depth:25mm
- Height:41mm
- Dimensions:45 x 25 x 41mm
- Core Material:Ferrite
- Maximum Self Resonant Frequency:10kHz
- Lead Pitch:10mm
- Series:B82726S
- Terminal Type:PC Pin
- CODE No.:871-1376
