Features

• UL60950-1, UL62368-1 / TUV EN60950-1, EN61558-1, EN61558-2-16 / CCC GB4943 / CB IEC60950-1, IEC62368-1. 3. RSP-150 Series Single Output Power Supply with PFC Function. The RSP-150 Series is a new generation of 150W AC/DC low profile, single output, enclosed type, switching power supply. This switch mode power supply reduced its height by 40%, from the 50mm of the previous models to 30mm. The RSP-150 features up to date high performance circuit topology, PFC function and possess up to 90% high efficiency. This enclosed power supply can be cooled by free air convection from -30°C to +40°C, or +50°C ambient temperature under full load condition and even +70°C by suitable derating. The RSP-150 features a remote ON/OFF control, short circuit, overload, over voltage and over temperature protection. This AC/DC power supply complies with the ITE requirements per UL, CUL, TUV, CCC, CB and CE regulations and also the TUV EN61558-1 and EN61558-2-16 certificates, fulfilling the ho***hold appliance requirements in the European market. Applications include industrial automation system, mechanical and electrical equipment, ho***hold appliance, instruments, or any systems that require 1U low profile installations. 30mm low profile design, suitable for 1U installation Universal AC input range 85 to 264V Built-in active PFC function High efficiency up to 90% Fan-less design, cooling by free air convection -30 to+70°C operating range Protection: Short circuit / Overload / Over voltage / Over temperature Built-in constant current limiting circuit Remote ON/OFF control LED indicator for power on 3 years warranty
