Electronic/Electrical Parts and Controll Equipments
63-7978-10 Sick W12-2 Laser Photoelectric Sensor Retroreflective 0 → 18 m Detection Range NPN/PNP WL12L-2B530
Product Description
Product Model: 63-7978-10Product Brand: Sick Features W […]
Contact Us
Product Details
Product Model: 63-7978-10
Product Brand: Sick
Features
- WT12 Laser Direct Detect. Plug-in style, 90° rotatable socket High accuracy sensing for small parts down to 0.5mm in a solid metal, IP67 housing Focusing light spot 0.1mm NPN or PNP dark ON/light ON selectable output Supply reverse polarity protected, output short circuit protected, interference suppression
Spec
- Quantity:1piece
- Sensor Style:Block
- Detection Type:Retroreflective
- Detection Range:0 → 18 m
- Output Type:NPN/PNP
- Electrical Connection:5-Pin M12 Connector
- Maximum DC Voltage:30V
- Light Source:Laser Light
- IP Rating:IP67, IP69K
- Maximum Current:100 mA
-
Response Time:
200 μs - Housing Material:Die Cast Zinc
- Maximum Operating Temperature:+50°C
- CODE No.:786-5918
