63-7785-55 Harting D-Sub Standard Series, 9 Way Through Hole PCB D-sub Connector Socket, 2.74mm Pitch, with 4-40 UNC Threaded 9661556513
Product Description
Product Model: 63-7785-55Product Brand: HARTING Feature […]
Contact Us
Product Details
Product Model: 63-7785-55
Product Brand: HARTING
Features
- D-Sub Miniature Connector, Hi-Temp, SMC Stamped Pins. A range of D-sub miniature connectors with high temperture resistance and stamped pins with SMC, suitable for cable to board and Ideal for communication and data interface D-sub connector applications. Durable D-sub connectors with a good mating cycle and a plated steel metal connector housing. Current capacity 6.5A Test voltage 1kV Contact resistance ≤10 mΩ Thermoplastic resin, glass filled Copper alloy contacts
Spec
- Quantity:1box(100pieces)
- Number of Contacts : 9
- G***er : Female
- Body Orientation : Straight
- Mounting Type : Through Hole
- Pitch : 2.74mm
- Mounting Hardware : 4-40 UNC Threaded Inserts, Boardlocks
- Current Rating : 6.5A
- Housing Material : Steel
- Length : 31.2mm
- Width : 6.2mm
- Depth : 12.5mm
- Dimensions : 31.2 x 6.2 x 12.5mm
- Series Number : 966
- CODE No.:923-1893
