Electronic/Electrical Parts and Controll Equipments
63-7752-09 TE Connectivity 2-Way IDC Connector Socket for Surface Mount, 1-Row 2106431-2
model:
63-7752-09
brand:
TE Connectivity
Product Description
Product Model: 63-7752-09Product Brand: TE Connectivity […]
Contact Us
Product Details
Product Model: 63-7752-09
Product Brand: TE Connectivity
Features
- Feed Through IDC SSL Connectors (SMT). IDC SSL feed through connectors that are designed for termination of discrete wires onto LED printed circuits boards. These IDC SSL connectors provide robust and stable electrical and mechanical power connection to single or multiple PCBs in solid state lighting and non-lighting applications. 18 - 24 AWG stranded and solid wire Dual IDC slots for redundancy Wire placement "viewing" window Wire gauge colour coded Tool-less termination
Spec
- Quantity:1piece
- Number of Contacts : 2
- Number of Rows : 1
- G***er : Female
- Pitch : 4mm
- Mounting Type : Surface Mount
- Body Orientation : Right Angle
- Termination Method : Solder
- Current Rating : 8.5A
- Contact Plating : Tin over Nickel
- Series : SSL
- Minimum Operating Temperature : -40°C
- Maximum Operating Temperature : +105°C
- Voltage Rating : 250 V dc, 250 V ac
- Housing Material : Thermoplastic
- CODE No.:718-4852
