Features

• UL. TE Connectivity SMT Telecom/Signal Relay P2 V23079 Series. P2 V23079 series DIP vertical mount SMT signal / telecom relays with a 15 x 7.5mm slimline design and 2A DPDT bifurcated gold plated silver nickel contacts. These SMT signal relays are immersion cleanable, have overmolded monostable coils (apart from stock number < 718-1998') 718-1998/ which has a monostable high dielectric coil) and offer a high sensitivity resulting in a low 140mW/70mW power consumption. Stock numbers < 515-565') 515-565/, < 515-577') 515-577/ and < 756-1274') 756-1274/ have long SMT pins whilst < 718-1812') 718-1812/ and < 718-1998') 718-1998/ have short SMT pins. Typical applications for these P2 V23079 series DIP vertical mount SMT signal relays include communications equipment (ringing and test access, PABX and VOIP), consumer electronics (set top boxes & HiFi), office, control, medical and automotive equipment. 2 pole polarised telecom and signal relay with an overmoulded single coil Long or short SMT legs Bifurcated contacts, gold plated Immersion cleanable, RTIII, IP67 V-0 flammability classification Insulation resistance at 500Vdc >10 9 Ω High sensitivity resulting in low nominal power consumption - 140mW Surge capability meets Telcordia TR-NWT-001089 (2 / 10 μs) and IEC 60950 (10 / 700 μs), 2000V between open contacts and 2500V between coil and contacts Applications include; Communications equipment (ringing and test access, PABX and VOIP), Consumer electronics (Set Top Boxes & HiFi), Office, Control, Medical and Automotive equipment
