63-7729-97 Vishay, BPW21R Visible Light Si Photodiode, 50 °, Through Hole TO-5 BPW21R
Product Description
Product Model: 63-7729-97Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-7729-97
Product Brand: Vishay
Features
- BPW20 and BPW21 Series Photodiodes. The BPW20 and BPW21 series of silicon photodiodes, from Vishay Semiconductor, are in standard TO-5 packages. These packages have been hermtically sealed, making the BPW20 and BPW21 ideal for high precision linear applications. Suitable applications for the BPW20 and BPW21 photodiodes include; sensors for light measuring in cameras, photometers, colour analysers, exposure meters and other general medical/industrial measuing and control applications.. Features of the BPW20 and BPW21 photodiodes: TO-5 package with flat glass lens 8.13 mm diameter Radiant sensitive area: 7.5 mm² High photo sensitivity Angle of half intensity: 50° Low dark current High linearity
Spec
- Quantity:1box(500pieces)
- Spectrums Detected : Visible Light
- Wavelength of Peak Sensitivity : 565nm
- Package Type : TO-5
- Mounting Type : Through Hole
- Number of Pins : 2
- Diode Material : Si
- Minimum Wavelength Detected : 420nm
- Maximum Wavelength Detected : 675nm
- Length : 9.1mm
- Width : 9.1mm
- Height : 3.1mm
- Angle of Half Sensitivity : 50 °
- CODE No.:177-7627
