63-7637-55 Amphenol 2.74mm Pitch 15 Way Straight Male Screw Terminal D-sub Connector L717D A15P ST
Product Description
Product Model: 63-7637-55Product Brand: Amphenol Featur […]
Contact Us
Product Details
Product Model: 63-7637-55
Product Brand: Amphenol
Features
- D-Sub Connectors. Male and female D-Sub connectors with direct screw connections These D-Sub's are all 2 Row Connectors. Easy wiring without the need for any special tool (a standard electrician's screwdriver can be ***d), ideal for field applications Applications: industry (control and automated systems), buildings services (lighting, air conditioning), infrastructure (remote control, public lighting, etc.) Also available as a kit with its hood, plastic or metal, with straight or right-angle cable entry (see stock for example no. ; 615-5960 615-5960 )
Spec
- Quantity:1piece
- G***er : Male
- Number of Contacts : 15
- Body Orientation : Straight
- Pitch : 2.74mm
- Contact Material : Brass
- Contact Plating : Gold over Nickel
- Housing Material : Steel
- Current Rating : 7.5A
- Voltage Rating : 300 V ac
- Dimensions : 39.52 x 12.93mm
- Mounting Type : Cable Mount
- Depth : 18.32mm
- Maximum Operating Temperature : +85°C
- CODE No.:615-5875
