63-7599-53 TRACOPOWER TES 2N 2W Isolated DC-DC Converter Surface Mount, Voltage in 9 → 18 V dc, Voltage out 5V dc TES 2N-1211
Product Description
Product Model: 63-7599-53Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-7599-53
Product Brand: TRACOPOWER
Features
- Operating temperature is without derating. 3. Traco 2W SMD Single/Dual Output Regulated Isolated DC-DC Converter - TES 2N Series. Low profile SMD package 1500Vdc input / output isolation Wide 2:1 input range Input filter to meet EN55022 Class A Indefinite short circuit protection
Spec
- Quantity:1set(10pieces)
- Output Voltage : 5V dc
- Input Voltage Range : 9 → 18 V dc
- Input Voltage Nominal : 12 V dc
- Isolation Voltage : 1.5kV dc
- Power Rating : 2W
- Output Current : 400mA
- Mounting Type : Surface Mount
- Number of Outputs : 1
- Efficiency : 77%
- Package : SMD
- Load Regulation : ±0.75%
- Maximum Temperature : +85°C
- Series : TES 2N
- CODE No.:161-6550
