63-7568-43 Recom REC3 3W Isolated DC-DC Converter Through Hole, Voltage in 9 → 18 V dc, Voltage out 5V dc Medical Approved REC3-1205SRW/H4/A
Product Description
Product Model: 63-7568-43Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-7568-43
Product Brand: Recom
Features
- EN60950-1, UL60950-1, EN60601-1. Operating temperature is without derating. Recom 3W DIP Single/Dual Output Regulated Isolated DC-DC Converter - REC3 Series. 2kVDC (H2 suffix) 4kVdc (H4 suffix) or 6kVdc (H6 suffix) Isolation Regulated outputs 2:1 or 4:1 (Z suffix) wide range input Efficiency up to 85% UL94V-0 package material Short circuit protection, auto restarting DIP24 miniature package
Spec
- Quantity:1piece
- Output Voltage : 5V dc
- Input Voltage Range : 9 → 18 V dc
- Input Voltage Nominal : 12 V dc
- Isolation Voltage : 4kV dc
- Power Rating : 3W
- Output Current : 600mA
- Mounting Type : Through Hole
- Number of Outputs : 1
- Medical Approved : Yes
- Package : DIP
- Minimum Temperature : -40°C
- Maximum Temperature : +85°C
- Depth : 10.2mm
- CODE No.:473-5390
