63-7349-83 TE Connectivity 1 Gang Rotary Cermet Potentiometer with a 6.35 mm Dia. Shaft, 47kΩ, ±10%, 2W, Linear 404802692040 404802692040
model:
63-7349-83
brand:
TE Connectivity
Product Description
Product Model: 63-7349-83Product Brand: TE Connectivity […]
Contact Us
Product Details
Product Model: 63-7349-83
Product Brand: TE Connectivity
Features
- metal lock washer and nut. 21mm M Series. Rugged construction with alloy housing High power rating (2W @ 70°C) Carbon brush wiper Metal bush and shaft Tolerance ±10% Rotation 270° Operating Temperature: -55 to +125°C
Spec
- Quantity:1box(50pieces)
- Potentiometer Type : Rotary
- Maximum Resistance : 47kΩ
- Number of Gangs : 1
- Number of Turns : 1
- Power Rating : 2W
- Electrical Taper : Linear
- Element Material : Cermet
- Mounting Type : Panel Mount
- Termination Style : Pin
- Shaft Length : 25.4mm
- Shaft Diameter : 6.35 mm
- Tolerance : ±10%
- Series : M
- CODE No.:135-4428
