63-7344-03 ON Semiconductor SMBJ22CA, Bi-Directional TVS Diode, 600W, 2-Pin DO-214AA SMBJ22CA
model:
63-7344-03
brand:
ON Semiconductor
Product Description
Product Model: 63-7344-03Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-7344-03
Product Brand: ON Semiconductor
Features
- Transient Voltage Suppressors SMT Bidirectional 600W, SMBJ Series, Fairchild Semiconductor. Glass-Passivated Junction 600W Peak Pulse Power Capability Excellent Clamping Capability Low-Incremental Surge Resistance Fast Response Time UL Certificate #E258596 UL94V-0 Flammability Classification
Spec
- Quantity:1bag(50pieces)
- Diode Configuration : Single
- Maximum Clamping Voltage : 35.5V
- Minimum Breakdown Voltage : 24.4V
- Mounting Type : Surface Mount
- Package Type : DO-214AA (SMB)
- Maximum Reverse Stand-off Voltage : 22V
- Pin Count : 2
- Peak Pulse Power Dissipation : 600W
- Maximum Peak Pulse Current : 16.9A
- Number of Elements per Chip : 1
- Minimum Operating Temperature : -55 °C
- Maximum Operating Temperature : +150 °C
- Width : 3.95mm
- CODE No.:802-2317
