1-9387-41-22 Ceramic Hot Plate (Digital Type) 550°C 175 x 178 mm with Pre-shipment Inspection Document CHP-170DF
Product Description
Product Model: 1-9387-41-22Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 1-9387-41-22
Product Brand: AS ONE Corporation
Features
- Digital type allows temperature setting by button input (10°C unit).
- Ceramic glass plate with excellent heat and chemical resistance.
- Can be ***d for high temperature heating up to 550°C.
- The warning lamp lights up when the top plate becomes hot.
Spec
- Model Number: CHP-170DF
- Maximum temperature (°C): 550
- Plate Size (mm): 175 x 178
- Type: Digital
- Material: Plate/Ceramic, Body/Aluminum Die Cast (Heat Resistant Coating)
- Temperature control system: PID control by K thermocouples
- Heater Capacity: 900 W
- Safety Device: Overcurrent F***, Internal Temperature F***, High Temperature Warning Display Function
- Power: 100 VAC 50/60Hz
- Heating Plate Size (mm): 155 x 159
- Size: 194 x 292 x 104 mm
- Weight: 2.5 kg
- This product can provide inspection and inspection services. Please contact us.
- *The inspection and inspection service is a service that inspects the control system (internal temperature measurement, etc.) and the electric locomotive at the time of shipment or at the customer's site, and issues inspection reports.
