63-6665-72 RS PRO, 6V dc Coil Non-Latching Relay SPDT, 10A Switching Current PCB Mount Single Pole 476-684
Product Description
Product Model: 63-6665-72Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-6665-72
Product Brand: RS PRO
Features
- IEC60335-1
- UL (File No. E133481), VDE (File No. 40010480), CQC (File No. CQC 04001011425)
- Ultra-low profile relay
- Low profile, maximum height: 12.5 mm 10 A switching capacity 3.2 mm Pinning isolation breakdown voltage: 5 kV (between coil and contact) Maximum surge voltage: 10 kV (between coil and contact) Resistant creepage distance: 8 mm or more Complies with VDE 0435/0631/0700
Spec
- Coil Voltage:6V dc
- Coil Power:290mW
- Coil Resistance:164 Ω
- Isolation Coil To Contact:5kV ac
- Contact Configuration:SPDT
- Mounting Type:PCB Mount
- Switching Current:10A
- Terminal Type:Through Hole
- Number of Poles:1
- Maximum Switching Voltage AC:440V ac
- Maximum Switching Voltage DC:125V dc
- Height:12.5mm
- CODE No.:476-684
