61-7643-15 Tube Fitting Chemical Union Tee φ4 Clean Package APE4-C
Product Description
Product Model: 61-7643-15Product Brand: NIHON PISCO CO. […]
Contact Us
Product Details
Product Model: 61-7643-15
Product Brand: NIHON PISCO CO., LTD.
Features
- The body material ***s PPS with excellent heat resistance, flame resistance (equivalent to UL94 V-0) and chemical resistance.
- FKM is ***d for the seal part.
- All parts ***d are non-oil.
- No need to worry about rust or metal ions. • Clean with clean air and wrap in a clean room (ISO Class 6 equivalent).
Spec
- Fluid ***d: Air, Water (*1. water, When you *** liquid, Keep surge pressure to the maximum operating pressure or less. 2. Water, When you *** liquid, Be sure to *** an insert ring. )
- Fluid ***d: Other chemicals (*1. water, When you *** liquid, Keep surge pressure to the maximum operating pressure or less. 2. Water, When you *** liquid, Be sure to *** an insert ring. 3. Chemicals, Solvent, for mixed gas, etc., Conformity of our specifications may vary dep***ing on usage conditions. Please contact with the nearest office. )
- Maximum operating pressure: 0.9MPa
- Used vacuum pressure: -100kPa
- Operating temperature range: 0 - 80℃
- RoHS supported
- Shape: UNION TEE
- Applicable tube size (outer diameter): φ4mm
- Seal material: FKM
- Package specification: Clean room packaging
