63-5126-58 RS PRO 1 Pair Aluminium Foil-PET Tape Multipair Industrial Cable 0.76 mm²(Euroclass Eca) Grey 100m 812-4684
Product Description
Product Model: 63-5126-58Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-5126-58
Product Brand: RS PRO
Features
- These cables are not to be regarded as power cables or cables for the direct connection of equipment to mains power supplies. Overall Screened Single Pair. A single twisted pair cable with tinned copper conductors insulated with polyethylene, wrapped in an aluminised tape with a tinned drain wire (same size as conductor) and a PVC outer sheath.,UL style 2092.
Spec
- Quantity：1roll(100m)
- Number of Pairs : 1
- Cross Sectional Area : 0.76 mm²
- Cable Type : Multicore
- American Wire Gauge : 22 AWG
- Outer Diameter : 4.5mm
- Shield Type : Aluminium Foil-PET Tape
- Outer Sheath Material : PVC
- Sheath Colour : Grey
- Core Strands : 7/0.254 mm
- Length : 100m
- CODE No.:812-4684
