Features

• 3M IDC ribbon cable (representative part number); 120-8413 120-8413). Dedicated tools also available – part number; See 120-6962 120-6962 and its series.
• IDC Wire Mount Plug (MDR) with Shield
• This 3M 101 Series Mini D-Ribbon (MDR) connector product is a 0.050 inch IDC wire mount shielded plug.
• The 101 series is designed for IDC termination of individual cores and wiper-on-wiper contacts.
• Fits a wide variety of configurations including round, flat, twisted pair, and twinax.
• Features and Benefits: Can be ***d with metal backshell series, part number; 163-3358 163-3358 and the representative part number; Refer to 194-2949 194-2949 for superior EMI/ESD protection PCB receptacle and engagement, representative part number; Refer to 499-9752 499-9752
• The 3M IDC wire mount plug includes:
• 101xx-6000 E x = Gold Flash Plating on Nickel IDC Plating 101xx-6000x L = 0.2 μm Gold Plating on Contact, Lubricated Gold Flash Plating on Tail 101xx-6000x C = 0.76 μm Gold Plating on Contact, Gold Flash Plating on Tail 101xx-6x 0 xxx = Black Cover 101xx-6x 1 xxx = Gray Cover
