63-5036-38 PCB Slide Switch Single Pole Double Throw (SPDT) Latching 5 A @ 28 V dc Top 734-7319
Product Description
Product Model: 63-5036-38Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-5036-38
Product Brand: RS PRO
Features
- RS - Miniature Slide Switches. Suitable for wave soldering at 260ºC for 5 seconds Black nylon actuator, DAP case and stainless steel housing Typical applications include PCB or front panel control for hand held products, instrumentation, white goods, medical, IT and telecomms equipment
Spec
- Quantity：1piece
- Contact Configuration : Single Pole Double Throw (SPDT)
- Mounting Type : PCB
- Switch Operation : Latching
- Contact Current Rating : 5 A @ 28 V dc
- Terminal Type : Through Hole
- Actuator Type : Top
- Length : 12.7mm
- Width : 6.6mm
- Dimensions : 12.7 x 6.6mm
- Contact Resistance : 10mΩ
- Mechanical Life : 30000Cycles
- Voltage Rating : 28V dc
- CODE No.:734-7319
Related product recommendations
You may also be interested in the following products
Electronic/Electrical Parts and Controll Equipments
63-6910-25 DC-DC Converter Non- Insulation high voltage Type 1 800 microA -1.2 kV 1 W CA12N-5
