Spec

• Filtration area, m

  ²

  : 0.5
• Width, cm (inch): 17.8 (7.0)
• Required pre-filtration level, μm: 100
• Length, cm (inch): 21 (8.3)
• Height, cm (inch): 2.16 (0.85)
• Screen material: Polypropylene
• Adhesive material: Polyurethane
• Material: Composite regenerated cellulose
• Filter code: PLCXK
• Brand name: Pellicon
• Main application: Protein Purification;Analytical Sample Prep
• Quantity/box: 1
• Overview: Pellicon 2 cassette ultrafiltration module PLCXK V 0.5m

  ²

• Product name: Pellicon 2 cassette
• NMWL, kDa: 1000
• pH range: 2?13
• Screen Type: V
• Filter type: Ultrafiltration
• Cycle flow rate, L/min: 5?35 @ 40


  kPa (6


  psi)
• Maximum transmembrane pressure difference (normal direction), kPa (psig): Normal direction - 345 (50) at 30℃; reverse direction - 34 (5)
• Total extract: The extractables level was equal to or less than 1500


  mg/m2 after a water flush.
• ※We ask for your kind understanding that lead time might change If it is out of stock in Japan.
