65-3536-02 ［Out of stock］Tape Type Temperature Sensor Model 503 w/ISO Document -50~210°C 3 sec E Type 503E-TC1-ASP
Product Description
Product Model: 65-3536-02Product Brand: ANRITSU METER C […]
Contact Us
Product Details
Product Model: 65-3536-02
Product Brand: ANRITSU METER CO., LTD.
Features
- Model 503/505 is more resilient than ST series. Model 540 is a tape-type temperature sensor with a disk-shaped tip that is easy to stick and a flexible tape.
- [Application] Surface temperature measurement of metals and non-metals, etc.
Spec
- Operating temperature range (°C): -50~210
- Tolerance at 100 deg. C (deg. C): ±2.5
- Response Time (sec): 3
- Thermocouple Type: E Type
- Code Type: Standard Code
- Cord length (m): 1
- Plug Shape: Standard Plug
- Calibration temperature point: 100°C
- Document content: Inspection report, calibration certificate, traceability system diagram
Related product recommendations
You may also be interested in the following products
toner
65-4283-36-20 Normal Pressure Gauge (Φ100) Vertical A-Frame for Heat and Vibration Resistance with 0.16 MPa with Inspection Certificate AE20-131
