61-1871-56 ［Discontinued］Avio Infrec F30S
Product Description
Product Model: 61-1871-56Product Brand: Nippon Avionics […]
Contact Us
Product Details
Product Model: 61-1871-56
Product Brand: Nippon Avionics Co., Ltd.
Features
- Anyone can easily take thermal images using a digital camera.
- It is small and lightweight with a pocket size of only 300 g.
- Equipped with a visible camera, you can leave a visible image as well as a thermal image.
- Focus is free and focus is not required beyond 1.3 m.
- Two types are available: the F30S, which can measure temperatures below 100°C with high sensitivity, and the F30W, which can measure temperatures up to 350°C.
Spec
- Measurement temperature range (℃): -20 - 100
- Temperature minimum display (℃): 0.1
- Measurement view angle (°): 28 x 21
- Space resolution (mrad): 3.1
- Mass (g): 300
- Power supply: AC adapter (AC100V), AA nickel hydrogen rechargeable battery x 3 (included)
- Width x depth x height: 100 x 45 x 65mm
- Detector number of pixels: 160 x 120
- Recording number of pixels: 160 x 120
- Frame rate: 8.5Hz
- Visible camera number of pixels: 1300000
- Container protection grade: IP43
- EMC: CE conform standards (class A)
- Dust control, spray-proof structure: Equivalent to protection grade IP43
- Vibration/impact: 3G/30G
- Application: Power facilities, Mechanical equipment, for maintenance of furnace material. for energy conservation diagnosis. for thermal evaluation or analysis of research and development.
- Production country: Japan
- Weight: 0.3kg
- Manufacturer's model number: F30S
- Code number: 486-6037
Related product recommendations
You may also be interested in the following products
toner
1-622-11-20 Calibration Certificate with Palma II Type Hygrometer Thermometer 7562-00
model: 1-622-11-20
brand: Sato Keiryoki Mfg. Co., Ltd.
toner
toner
62-3399-27 glycerin-filled Pressure Gauge GV501230.2MP
