Spec

• Model number: GL820
• Size (mm): Approx 232 x 152 x 50
• Weight (g): 900
• System: Scan method, tall ch insulation, balanced input
• Sampling cycle: 10ms - 1h (10 - 50ms is only for voltage, ch restriction applies dep***ing on the sampling period)
• Alarm output: Number of channels/4ch
• PC I/F: Ethernet (10BASE-T/100BASE-TX), USB (Hi-Speed)
• Data retention function: Measurement data/direct recording to built-in memory or USB memory, Other/setting conditions, screen copy data can be stored in the built-in memory or USB memory
• Number of unit loading analog terminal: 1 unit (20ch) or expansion unit (maximum 200ch)
• Incorporated memory: 2GB (available to expand external USB memory)
• Power supply: AC100 - 240V, 50/60Hz, AC adapter (included) or DC drive (DC8.5 - 24V, optional)
• Weight: Approx 900g
•

• Voltage: 20, 50, 100, 200, 500mV, 1, 2, 5, 10, 20, 50V, 1-5VFS
• Temperature: Thermocouple/K, J, E, T, R, S, B, N, W (WRe5-26), Resistance thermometer/Pt100, JPt100, Pt1000 (IEC751)
• Humidity: 0 - 100% (voltage 0 - 1V scaling conversion) *When loading B-530 option
