65-9010-41 ［Discontinued］Compressor DPA0105-Y1
Product Description
Product Model: 65-9010-41Product Brand: NITTO KOHKI CO. […]
Contact Us
Product Details
Product Model: 65-9010-41
Product Brand: NITTO KOHKI CO., LTD.
Features
- Compressors only.
Spec
- Discharge Air Amount (L/min): 2.8
- Rated voltage (V): DC24
- Maximum pressure (kPa{kgf/cm2}): 220{2.2}
- Maximum current (A): 0.7 or less
- rated time: continuous
- Useful Time (MTTF) (hours): 5000
- Working Pressure Range (kPa{kgf/cm2}): 0~100{0~1}
- Discharge Port Size (mm): Φ5 (Outer Diameter)
- Coil Insulation Class: Equivalent to Class A
- Mounting Dimensions (mm): 32 (L) x 27.5 (W)
- Body mass (kg): 0.30
- Lead wire length (mm): 360±20
- Specifications: (DC Drive) Cup Seal System/(Brushless) DC Motor/Compressor
