1-5825-11-20 ［Discontinued］Digital Temperature Controller (With Program Function) -100 - 600℃ With Calibration Certificate TP-4NK
Product Description
Product Model: 1-5825-11-20Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 1-5825-11-20
Product Brand: AS ONE Corporation
Features
- Temperature control is an ON/OFF control method.
- As for the temperature display, the PV/SV two-stage display is adopted so that the measured value and the set value can be seen at a glance to prevent setting errors.
- Equipped with a program function, up to 8 steps and 4 patterns can be set.
- Forward/reverse operation switching is possible.
- It is equipped with circuit protector, alarm output function and sensor malfunction detection function.
Spec
- Model number: TP -4 NK
- Set temperature: 100 to 600 ℃
- Minimum display unit: 1 ℃
- Temperature display accuracy: ±0.5% (FS) ±1 digit or 3 ℃, whichever is larger
- Temperature control method: ON/OFF control
- Temperature setting display: Sheet key touch system, PV/SV digital two-stage display
- Sensor type: K class thermocouple (φ4 x 200mm)
- Connected capacity: AC100V 50/60Hz MAX 12 A (resistance load) * Do not connect inductive load devices (Motor, pumps, etc.) directly to the tester.
- Additional functions: Program functions/8 steps 4 patterns
- Safety function: Circuit protector (15 A), alarm output function, sensor abnormality detection
- Power supply : AC100V 50/60Hz
- Main unit size: 95 x 150.6 x 48.5mm (excluding projections)
- Accessories: Calibration certificates
- *Products with calibration certificate is a service where equipment is calibrated and calibration certificate is issued at the time of shipment.
Related product recommendations
You may also be interested in the following products
toner
65-3631-73 KOT Small Pressure Gauge Core Section SUS A Type φ50 R1/4 0~0.2MPA S-ADTR14-500.2MPA
