3-8115-01-22 ［Discontinued］Film Chuck Hot Plate 120 x 120 Waterproof with Pre-shipment Inspection Document PA2012-WPFC
model:
3-8115-01-22
category:
laboratoryinstruments
Product Description
Product Model: 3-8115-01-22 Features The adsorption par […]
Contact Us
Product Details
Product Model: 3-8115-01-22
Features
- The adsorption part is a ceramic sintered body that can precisely heat the film-like workpiece.
- It is also suitable for built-in applications.
Spec
- Model number: PA2012-WPFC
- Top Plate Adsorption Size (mm): 120 x 120
- Waterproof: Yes
- Operating Temperature Range: Room Temperature ~200°C
- Temperature distribution accuracy: ±1.5%
- Plate Part: Ceramic Porous Body
- Vacuum Port: One-touch Joint for Outer Diameter Φ6mm
- Recomm***ed vacuum pump: Diaphragm pump (exhaust speed 20 L/min)
- Power: 100 VAC 50/60Hz
- Electrical Capacity: 800 W
- Power Cable Length: 1.5 m (Tip R3.5 Crimp Terminal)
- Sensor Cable Length: 1.5 m (Tip R3.5 Crimp Terminal)
