Spec

• Temperature point: 210°C9 points
• Interior Dimensions (mm): 300 x 300 x 300
• External Dimensions (mm): 410 x 451 x 670
• Convection Methods: Forced Convection
• Performance: Temperature Adjustment Range/Room Temperature +10~260°C, Maximum Temperature Reaching Time/Approx. 60 Minutes (Room Temperature +10~210°C)/Approx. 90 Minutes (Room Temperature +10~260°C)
• Functions: Temperature Control/PID Control, Timer/1 minute ~99 hours 59 minutes and 100 hours ~999 hours 50 minutes (with Timer Weight Function), Safety Device/Self-Diagnosis Function (Temperature Sensor Abnormality/Automatic Excess Rise Prevention), Key Lock, Indep***ent Excess Rise Prevention Device, Leakage Breaker with Overcurrent
• Internal Capacity: 27 L
• Material: Exterior/Chromium-Free Electrogalvanized Steel Plate/Chemical-Resistant Baking Coating, Interior/Stainless Steel, Insulation/Glass Wool
• Power: 100 VAC 50/60Hz 8.5 A (15 A)
• Shelf Board Load Capacity: 15 kg/Sheet
• Weight: Approx. 35 kg
• Accessories: Stainless Steel Punched Shelf Board x 2, Shelf Receiver x 4 (Bottom-most 1 is Screw-Stopped)
• *Transportation, loading, installation and assembly costs are required separately. Please contact us.
• On-site validation services (IQ/OQ) are also available.
• Please contact us.
• *On-site validation service is a service where installation qualification (IQ) and operational performance qualification (OQ) are performed and inspection documents are submitted at the installation site.
• *Do not put flammable materials into the container.
• *If you would like IQOQ on site, please contact us separately. The installation address is required for the quotation.
