Spec

• Record Mode: Normal, Trigger, Capture, power supply Quality
• Operation method: Sequential comparison method (CH1 signal synchronous sampling)
• rating Maximum Operating Voltage: 9.9 Vrms AC 14 V Peak
• Number of inputs: 3 ch
• measuring method: true rms operation
• RMS interval: Approx. 100 ms
• Sampling interval: normal/trigger recording mode approximately 1.65 msec/CH
• Sampling interval: Capture recording mode approximately 0.55 ms (waveform: approximately 1.1 ms interval)
• Sampling interval: power supply Quality Record Mode Approx. 0.55 ms
• battery Voltage Warning: Four-level battery Mark
• Input over display: display when measurement range is exceeded "OL"
• Auto power off function: power supply is turned off about 3 minutes after switch operation (when recording is stopped).
• power supply: 6 VDC (AA size battery x 4 pieces)/external power supply (dedicated AC adapter)
• Can be ***d continuously: about 10 days (AA size Alkali battery LR6)
• Withstand voltage: 3536 VAC (50/60 Hz rms)/5 seconds
