65-9008-06 ［Discontinued］TSP Coupler Screw Size Rc3/8 Brass 108 g 3TSMBRASSFKM
Product Description
Product Model: 65-9008-06Product Brand: NITTO KOHKI CO. […]
Contact Us
Product Details
Product Model: 65-9008-06
Product Brand: NITTO KOHKI CO., LTD.
Features
- For medium pressure.
- Since it is a valveless structure, pressure loss is greatly reduced and large flow rate is obtained.
- Suitable for fluids with high viscosity (such as grease).
- Various body materials, sizes and mounting shapes have been standardized to meet a wide range of applications and conditions.
- Compatibility: The socket and plug can be connected regardless of the mounting configuration, as long as the initial letters of the product type are the same.
Spec
- Mating Side Mounting Screw Size: Rc3/8
- Body Material: Brass
- Mass (g): 108
- L(mm):46
- ΦD(mm):28
- H (mm): Hex 23
- T:R3/8
- ΦB(mm):10
- Valve Structure: Double Road Open Type
- Maximum Working Pressure (MPa{kgf/cm2}): 5.0{51}
- Pressure Capacity (MPa{kgf/cm2}): 7.5{76}
- Recomm***ed maximum tightening torque (N · m{kgf · cm}): 12{122}
- Seal Material: Fluororubber
- display symbols: FKM
- Operating Temperature Range (°C): -20 to +180
- Remarks: Standard Material
- Mounting Shape: Male Screw
- Type: Socket
